Rechargeable Lifepo4 Cell 3.2V 6000mAH

Cylindrical Cells

Features:

Benergy cylindrical cells are in standard AA, AAA, 18650, 26650, 32700 size. Cells are more flexible to make different battery packs. Long cycle life. High safety. Can be used for different devices, power tools, electronic products etc.

Model:

BNG322700-6000

Voltage:

3.2V

Capacity:

6000mAH

Max Charge Current:

6000mAh (1C)

Max Continuous Discharge Current:

18000mAh (3C)

Size:

32.2*70.8mm (Diameter, height)

Size in inch:

1.27*2.79 (Diameter, height)

Weight:

140g±150g

Weight in pound:

0.31 lb

Cycle life:

3000+ cycles

Brand:

Benergy

Inquiry

Write a Review

Specification

Item		Condition/ Note	Specification	Remarks
2.1 Nominal Capacity		1C discharge capacity	6000mAh
2.2 AC Impedance		At AC 1000 Hz	≤6.5mΩ
2.3 Nominal Voltage			3.2 V
2.4 Cell Size		Cell Diameter	32.2±0.3 mm Max. 32.5 mm	For details, please prefer to Figure 1.
2.4 Cell Size		Cell Height	70.5±0.3 mm Max. 70.8mm	For details, please prefer to Figure 1.
2.5 Cell Weight		（Cell net weight）	140± 5 g
2.6 End-of-charge Voltage		CC Mode	3.65 V
2.7 End-of-charge Current		CV Mode	0.3 A
2.8 Charging Method		Standard Charging	1 C at CC/CV	60 min
2.8 Charging Method		Max Continuous Charging	6 C at CC/CV	10 min
2.9 End-of-discharge Voltage		CC Mode	2.0 V
2.10 Max continuous Discharging Current			18A
2.11 Max Pulse Discharging Current			60A	3s
2.12 Cycle Life		1 C/ 100 % DOD	≥4000 cycles
2.13 Operating Temperature Range	Charging Temperature		0~60 °C
	Discharging Temperature		-20~ 60°C
	Storage Temperature	1 year	-20~ 45°C
2.14 Appearance		Without break, scratch, distortion, contamination, leakage and so on

Discharge curves

测试曲线 (2)

测试曲线 (3)

测试曲线 (1)

32700 cells 9

Why choose Benergy Lifepo4?

Rechargeable Lifepo4 Cell 3.2V 6000mAH 11

Design

Safety is the most important for battery using.

Rechargeable Lifepo4 Cell 3.2V 6000mAH 12

Brand

Resisted our own Brand: BENERGY in European Union and HK. Welcome OEM, ODM.

Rechargeable Lifepo4 Cell 3.2V 6000mAH 13

Service

* Can arrange the shipping for customers.
* Can customize the battery pack.

Rechargeable Lifepo4 Cell 3.2V 6000mAH 14

Quality

* Professional Lithium Iron Phosphate Cell Maker since 2009 when Lifepo4 cell technology is still quite new.
* All cells are Level A 100% New Lifepo4 Cells
* 3.2V single lifepo4 cells , available both Aluminum Shell and Plastic Shell Prismatic Cells.
* With bar code/ QR code, can trace every cell information for the whole production process.
* Strict testing during every production step. Final testing before shipping.
* Provide testing data of each cell before shipping.

Applications of Benergy Lifepo4 Battery

Benergy Lifepo4 batteries can be widely used for Electric bike, Electric wheelchair, Electric scooter, Electric motorcycle, Golf cart, Electric robot, Vacuum cleaner, Electric mower, Wind/solar energy storage ...

图片2 (4)

What is an Lifepo4?

● LiFePo4 battery mean lithium Iron Phosphate battery which is a kind of lithium ion rechargeable battery. The single voltage is 3.2V and capacity can be 90mAH to 300AH.

● LiFePo4 batteries are the safest lithium battery type currently available on the market today. With characteristic of lighter weight, smaller size, longer cycle life, free maintenance, no pollution, no memory effect they can fully replace lead acid batteries and Ni-MH/Ni-CD batteries.

● Benergy has been producing and exporting Lifepo4 cells since 2009 and we have been providing quality, reliable and safe battery solutions world widely.

QQ图片20230609102409

QQ图片20230609102315

微信图片_20230211170445

Production machine and production line

图片3 (2)

Certifications

Benergy has got CE, ROHS, CB, ISO9001, IEC62133 certifcations.
