Model No.: BXL-32700AHP
Characteristic:
1. Can fully replace Ni-CD, Ni-MH, Alkaline battery, carbon battery. Voltage 3.2V, 1pcs to replace 2pcs.
2. Rechargeable, for long time use, more economical.
3. High Energy Density
4. Wide working temperature range: From -10℃ to 60℃, extremely cold and hot weather will not affect its performance.
Specification:
Item | Condition/ Note | Specification | Remarks | |
2.1 Nominal Capacity | 1C discharge capacity |
6.0 Ah | ||
2.2 AC Impedance | At AC 1000 Hz |
6.5 mΩ | ||
2.3 Nominal Voltage |
3.2 V | |||
2.4 Cell Size | Cell Diameter | 32.2±0.3 mm Max. 32.5 mm | For details, please prefer to Figure 1. | |
Cell Height | 70.5±0.3 mm Max. 70.8mm | |||
2.5 Cell Weight | (Cell net weight) |
140± 5 g | ||
2.6 End-of-charge Voltage | CC Mode |
3.65 V | ||
2.7 End-of-charge Current | CV Mode |
0.3 A | ||
2.8 Charging Method | Standard Charging |
1 C at CC/CV |
60 min | |
Max Continuous Charging |
6 C at CC/CV |
10 min | ||
2.9 End-of-discharge Voltage | CC Mode |
2.0 V | ||
2.10 Max continuous Discharging Current |
36 A | |||
2.11 Max Pulse Discharging Current |
60 A |
3s | ||
2.12 Cycle Life |
1 C/ 100 % DOD |
≥2000 cycles | ||
2.13 Operating Temperature Range | Charging Temperature |
0~60 °C | ||
Discharging Temperature |
-20~ 60°C | |||
Storage Temperature | 1 year |
-20~ 45°C | ||
2.14 Appearance | Without break, scratch, distortion, contamination, leakage and so on |
Discharge curves:
Details:
Other Benergy small batteries (Can customize for you if you need other types)
Applications of Benergy Lifepo4 Battery:
Here are some common uses for cylindrical cells:
Portable Electronics: batteries are commonly used in portable electronics like digital cameras, remote controls, flashlights, and portable gaming devices.
Toys and Games: Many children's toys and games require batteries to operate, such as remote-controlled cars, action figures, and board games.
Household Devices: batteries are also commonly used in household devices such as wall clocks, smoke detectors, and TV remotes.
Medical Devices: Some medical devices, such as blood glucose monitors, use AA batteries as a power source.
Camping and Outdoor Gear: AA batteries are a popular choice for camping and outdoor gear such as lanterns, GPS devices, and portable radios.
Emergency Lighting: AA batteries are commonly used in emergency lights and flashlights, as they are reliable and easy to replace.
...
Brand:
Quality:
* Professional Lithium Iron Phosphate Cell Maker since 2009 when Lifepo4 cell technology is still quite new.
Benergy can provide you the Lifepo4 single cells or battery packs based on your detail applications.
We're not satisfied until you are - contact us to see how we can exceed your expectations!
